Printing | |
Printing method | Dircet thermal |
Printing width | 79.5±0.5mm |
Column capactity | 576dots/line 512dots/line |
Printing speed | 70mm/s |
Interface | USB+Bluetooth / USB+Wifi / USB+Wifi+Bluetooth |
Paper thickness | 0.06~0.08mm |
Character size | ANK,Font A:1.5×3.0mm(12×24 dots)Font B:1.1×2.1mm(9×17 dots) simplified/traditional Chinese:3.0×3.0mm(24×24 dots) |
Barcode Character | |
Extension character sheet | PC347(Standard Europe)、Katakana、PC850(Multilingual)、PC860(Portuguese)、 PC863(Canadian-French)、PC865(Nordic)、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866(Cyrillic#2)、PC852(Latin2)、PC858、IranII、Latvian、Arabic、PT151(1251) |
Barcode types | 1D:UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128 2D:QR CODE/PDF417 |
Power | |
Power supply input | AC 110V/240V, 50~60Hz |
Power source | Output:DC 9V/2A |
Battery | 2000mAh |
Physical characteristics | |
Gross weight | 325g |
Dimensions | 136×116×60mm(D×W×H) |
Environmental Requirements | |
Work environment | 0~45℃, 10~80% RH |
Storage environment | -10~60℃, 10~90% RH(no condensation) |
Buffer | |
Input buffer | 32k bytes |
NV Flash | 64k bytes |
