Model

Model

DHI-LM22-A200

Display

Screen Size

22"

Panel type

VA

Aspect Ratio

16:9

Resolution

1920×1080 (FHD)

Backlight

LED

Brightness/Luminance

200 cd/㎡

Contrast

3000:1

Display Color

16.7M(8bit)

Viewing Angle(H/V)

178°(H)/178°(V)

Response time(typ.)

5ms

Refresh Rate

60Hz

Signals

Input

VGA×1, HDMI×1

General

Power Supply

DC 12V

Consumption (Standard)

30W

Consumption (Standby)

≤0.5W

Net Weight

2.42 kg (5.34 lb)

Gross Weight

3.1 kg (6.83 lb)

Bezel Width

3.1mm(R/L) 12.5mm(B)

Wall Mount

100×100mm

Dimension without standard (W×H×D)

496 × 285 × 51.5 mm (19.53" × 11.22" × 2.03")

Package(W×H×D)

546 × 123 × 358 mm (21.5" × 4.84" × 14.09")

Work Environment

Temperature

0℃~40℃ (32°F~104°F)

Humidity

20%~80%

Accessory

Standard

HDMI cable, adapter, base

Optional

Gas spring desk bracket

Certifications

Certifications

CE/FCC
